1200 Can/Min Can Inspection Equipment , SUS304 Can Testing Equipment

1200 Can/Min Empty Can Inspection Equipment , SUS304 Can Testing Equipment

Equipment overview:

    The empty can inspection machine integrates the most advanced camera and optical technology in the world, and judges whether the inspection item is qualified through the intelligent image analysis system and the expert decision system of the high-speed computer.
    The equipment is mainly composed of a negative pressure conveying part, a detection device (including the detection of foreign objects in the can and the can mouth), a man-machine interface, an industrial computer, a rejection device and a power distribution cabinet, etc., which is suitable for the detection of empty cans in a high-speed filling production line.

Principle of empty can detection:

    When the empty can enters the foreign body detection area in the can, the sensor gives the camera a trigger signal, where the ring light source lights up, and the camera takes a frame of images of the inner wall and bottom area of ​​the can, and transmits the image to the industrial computer. The industrial computer performs the image processing. Real-time processing to determine whether there are foreign objects in the can.
    When the empty can enters the inspection area of ​​the can mouth, it is the same as the previous station. The high-speed camera acquires the image of the can mouth under the low-angle circular light and transmits it to the industrial computer for processing. Finally, a comprehensive judgment of the two inspection stations As a result, if it is a defective product, when the detected can enters the reject area, the reject device rejects the defective product to the defective product collection station. If it is a genuine product, enter the next production process.

Technical parameters and features:

Accessory brands:
